Chemical Process Industry
Sealing elements: Overview Compounds For the Chemical Process Industry (CPI)
| Compound number | Material | Hardness IRHD ±5 | Application | Colour | Temp °C |
|---|---|---|---|---|---|
| TFE/P 223201 (80kB) More datasheets» |
TFE/P | 75 | Base resistant quality | black | -10 / +220 |
| EPDM 55914 PC (64kB) More datasheets» |
EPDM | 70 | Peroxide cured general purpose O-ring quality | black | -55 / +150 |
| FKM 514308 (127kB) More datasheets» |
FKM | 70 |
Standard cord quality |
black |
-20 / +200 |
| Genuine Viton® GLT 514115 (111kB) More datasheets» |
FKM | 70 | Original Viton GLT for low temperatures | black | -40 / +200 |
| Genuine Viton® A 51414 black (77kB) More datasheets» |
FKM | 75 | General purpose, good compression set | black |
-20 / +200 |
| Genuine Viton® A 51414 green (77kB) More datasheets» |
FKM | 75 | General purpose, good compression set | green | -20 / +200 |
| Genuine Viton® A 514206 (110kB) More datasheets» |
FKM | 75 | Good compression set cord and O-ring quality, also as Vulc-O-Ring | black |
-20 / +200 |
| Genuine Viton® A 514302 (94kB) More datasheets» |
FKM | 75 | Good compression set cord and O-ring quality, also as Vulc-O-Ring | brown |
-20 / +200 |
| Genuine Viton® GF 514141 (77kB) More datasheets» |
FKM | 75 | Original Viton GF-Terpolymer | black |
-10 / +200 |
| Genuine Viton® A 514306 (77kB) More datasheets» |
FKM | 75 | Good compression set, quality Vulc-O-ring | green |
-20 / +200 |
| Genuine Viton® GFLT 514712 (123kB) More datasheets» |
FKM | 75 | Good low temperature, better chemical resistance |
black | -40 / +200 |
| FKM 514322 (81kB) More datasheets» |
FKM | 75 | Lowest temperature for FKM |
black | -40 / +200 |
| Extreme ETP 514016 (76kB) More datasheets» |
FKM | 75 | Paint & spray industry |
black | -20 / +200 |
| Genuine Viton® 514301 (80kB) More datasheets» |
FKM | 80 | Standard compound |
black |
-20 / +200 |
| Genuine Viton® B 514021 (76kB) More datasheets» |
FKM | 80 | For better chemical resistance |
black | -20 / +200 |
| Genuine Viton® A 51480 (77kB) More datasheets» |
FKM | 80 | General purpose |
green |
-20 / +200 |
| Genuine Viton® A 514320 (77kB) More datasheets» |
FKM | 90 | General purpose, good compression set |
black |
-20 / +200 |
| Genuine Viton® A 514309 (93kB) More datasheets» |
FKM | 90 | Good compression set. Also as Vulc-O-ring |
black | -20 / +200 |
| Genuine Viton® 514204 (76kB) More datasheets» |
FKM | 90 | Explosive decompression grade |
black | -15 / +200 |
| Teflex Viton® (79kB) More datasheets» |
FKM-FEP/PFA |
High performance encapsulated O-ring |
black |
-20 / +200 |
|
| Teflex Silicone VMQ (85kB) More datasheets» |
VMQ-FEP/PFA |
High performance encapsulated O-ring |
red |
-60 / +260 |
|
| FKM 514162 (80kB) More datasheets» |
FKM |
95 |
Explosive decompression grade |
black |
-15 / +200 |
| Kalrez® Spectrum™ 6375 (115kB) More datasheets» |
FFKM |
75 |
Excell. chemical resistance / High temp. stability |
black |
275 |
| Kalrez® Spectrum™ 7075 (104kB) More datasheets» |
FFKM |
75 |
Very longer service life, Extreme good compression set, Excell, chemical resistance |
black |
327 |
| Kalrez® 4079 (89kB) More datasheets» |
FFKM |
75 |
Outstanding hot air aging |
black |
315 |
| Kalrez® 6380 on request More datasheets» |
FFKM | 80 | aggressive amines |
cream |
225 |
| Kalrez® 1050LF (172kB) More datasheets» |
FFKM | 82 |
General purpose, hot water/steam |
black | 280 |
| Kalrez® 2035 on request More datasheets» |
FFKM | 85 | General purpose, hot water/steam black 280 Good general purpose for |
black | 210 |
| Kalrez® 7090 on request More datasheets» |
FFKM |
90 |
CPI |
black |
325 |
| Kalrez® 3018 (172kB) More datasheets» |
FFKM |
91 |
For use in the oil field and process industries |
black |
280 |
