Food and Beverage Industry
High Performance O-rings and custom moulded parts
Selecting the right elastomer is a balance of material and design. All ERIKS compounds listed below are produced from listed ingredients. We distinguished the following grades:
| Compound number | Material ASTM D1418 | Colour | Hardness IRHD±5 | Certificates | Temp. resistance °C |
|---|---|---|---|---|---|
| 329303 (81kB) More datasheets» |
Neoprene |
black |
75 |
FDA 177.2600 aqueous & fatty foods, EC 1935, ADI free |
-35/+100 |
| 366312 (*) (99kB) More datasheets» |
Nitrile-NBR |
blue |
60 |
FDA 177.2600 aqueous & fatty foods, 3A, EC 1935, ADI free |
-30/+120 |
| 366470 (84kB) More datasheets» |
Nitrile-NBR |
black |
70 |
FDA 177.2600 aqueous & fatty foods, 3A, EC 1935, ADI free | -30/+120 |
| 366302 (85kB) More datasheets» |
Nitrile-NBR |
black |
75 |
FDA 177.2600 aqueous & fatty foods, 3A, EC 1935, ADI free |
-30/+120 |
| 366472 (80kB) More datasheets» |
Nitrile-NBR |
white |
75 |
FDA 177.2600 aqueous & fatty foods, EC 1935, ADI free | -30/+120 |
| 366480 (80kB) More datasheets» |
Nitrile-NBR |
black |
80 |
FDA 177.2600 aqueous & fatty foods, EC 1935, ADI free |
-30/+120 |
| 366490 (80kB) More datasheets» |
Nitrile-NBR |
black |
90 |
FDA 177.2600 aqueous & fatty foods, EC 1935, ADI free | -30/+120 |
| 886972 (81kB) More datasheets» |
HNBR |
white |
77 |
FDA 177.2600 aqueous & fatty foods, EC 1935, ADI free | -30/+150 |
| 886172 (80kB) More datasheets» |
HNBR |
black |
70 |
FDA 177.2600 aqueous & fatty foods, EC 1935 | -30/+150 |
| 886214(**) (92kB) More datasheets» |
HNBR |
red |
69 |
FDA 177.2600 aqueous & fatty foods, EC 1935, ADI free | -30/+150 |
| 559260 (136kB) More datasheets» |
EPDM |
black |
60 |
FDA 177.2600 aqueous & fatty foods, EC 1935 |
-40/+140 |
| 559311(*) (146kB) More datasheets» |
EPDM |
blue |
67 |
FDA 177.2600 aqueous & fatty foods, 3A, EC 1935, ADI free |
-40/+140 |
| 55641 (88kB) More datasheets» |
EPDM |
black |
70 |
FDA 177.2600 aqueous & fatty foods | -55/+150 |
| 559270 (79kB) More datasheets» |
EPDM |
black |
70 |
FDA 177.2600 aqueous & fatty foods, EC 1935, ADI free | -55/+150 |
| 559272 (79kB) More datasheets» |
EPDM |
white |
70 |
FDA 177.2600 aqueous & fatty foods, EC 1935, ADI free |
-55/+150 |
| 559273 (105kB) More datasheets» |
EPDM |
black |
70 |
FDA 177.2600 aqueous & fatty foods, USP Class VI, 3A, EC 1935, ADI free | -40/+150 |
| 55111 (255kB) More datasheets» |
EPDM |
black |
70 |
FDA 177.2600 aqueous & fatty foods, KTW, DVGW, NSF, WRAS, ACS, W-270, KIWA, EC 1935, ADI free | -55/+150 |
| 559274 (102kB) More datasheets» |
EPDM |
white |
70 | FDA 177.2600 aqueous & fatty foods, USP class VI, EC 1935, ADI free |
-40/+150 |
| 559302 (104kB) More datasheets» |
EPDM |
black |
70 |
FDA 177.2600 aqueous & fatty foods, USP Class VI, 3A, EC 1935, ADI free |
-50/+150 |
| 559187 (84kB) More datasheets» |
EPDM |
black |
75 |
FDA 177.2600 aqueous & fatty foods, 3A, EC 1935 | -40/+140 |
| 559280 (80kB) More datasheets» |
EPDM |
black |
80 |
FDA 177.2600 aqueous & fatty foods, EC 1935, ADI free | -40/+140 |
(**): Bio-Hygienic®
| Compound number | Material ASTM D1418 | Colour | Hardness IRHD±5 | Certificates | Temp. resistance °C |
|---|---|---|---|---|---|
| 514660 (94kB) More datasheets» |
FKM |
black |
60 |
FDA 177.2600 aqueous & fatty foods, EC 1935, ADI free |
-15/+200 |
| 514670 (93kB) More datasheets» |
FKM |
black | 70 |
FDA 177.2600 aqueous & fatty foods, EC 1935, ADI free | -20/+200 |
| 514328 (146kB) More datasheets» |
FKM |
blue |
70 |
FDA 177.2600 aqueous & fatty foods, 3A, EC 1935, ADI free | -15/+204 |
| 514642 (93kB) More datasheets» |
FKM |
green |
70 |
FDA 177.2600 aqueous & fatty foods, EC 1935, ADI free | -20/+200 |
| 514672(*) (94kB) More datasheets» |
FKM |
white |
70 |
FDA 177.2600 aqueous & fatty foods, EC 1935, ADI free | -15/+200 |
| 514674 (93kB) More datasheets» |
FKM |
blue |
70 |
FDA 177.2600 aqueous & fatty foods, EC 1935, ADI free | -20/+200 |
| 514002 on request More datasheets» |
FKM |
green |
75 |
FDA 177.2600 aqueous & fatty foods, EC 1935, ADI free | -20/+200 |
| 514010 (150kB) More datasheets» |
FKM |
white |
75 |
FDA 177.2600 aqueous & fatty foods, USP Class VI, 3A, EC 1935, ADI free | -20/+200 |
| 514304 (95kB) More datasheets» |
FKM |
white |
75 |
FDA 177.2600 aqueous & fatty foods, 3A, EC 1935, ADI free | -20/+200 |
| 514172 (96kB) More datasheets» |
FKM |
black |
75 |
FDA 177.2600 aqueous & fatty foods, 3A, EC 1935, ADI free | -20/+200 |
| 514641 (93kB) More datasheets» |
FKM |
black |
75 |
FDA 177.2600 aqueous & fatty foods, EC 1935, ADI free | -20/+200 |
| 514682 (94kB) More datasheets» |
FKM |
white |
80 |
FDA 177.2600 aqueous & fatty foods, EC 1935 | -15/+200 |
| 514683 (126kB) More datasheets» |
FKM |
black |
75 |
FDA 177.2600 aqueous & fatty foods, EC 1935 | -15/+200 |
| 514312 (120kB) More datasheets» |
FKM |
black |
75 |
FDA 177.2600 aqueous & fatty foods, USP Class VI, 3A, EC 1935, ADI free | -20/+204 |
| Genuine Viton® A 514680 (94kB) More datasheets» |
FKM |
black |
80 |
FDA 177.2600 aqueous & fatty foods, EC 1935, ADI free | -20/+200 |
| Teflex® Viton® (79kB) More datasheets» |
FKM/FEP/PFA |
black |
75 |
FDA 177.2600 aqueous & fatty foods, USP Class VI, FDA 177.1550, EC 1935, ADI free | -20/+200 |
| Genuine Viton® A 514690 (95kB) More datasheets» |
FKM |
black |
90 |
FDA 177.2600 aqueous & fatty foods, EC 1935, ADI free | -20/+200 |
| Genuine Viton® A 514694 (94kB) More datasheets» |
FKM |
blue |
90 |
FDA 177.2600 aqueous & fatty foods, EC 1935, ADI free | -20/+200 |
| Silicone 714742 (79kB) More datasheets» |
VMQ |
white |
40 |
FDA 177.2600 aqueous & fatty foods, EC 1935, ADI free | -60/+200 |
| Silicone 714747 (79kB) More datasheets» |
VMQ |
transl. |
40 |
FDA 177.2600 aqueous & fatty foods, EC 1935, ADI free | -60/+200 |
| Silicone 714748 (79kB) More datasheets» |
VMQ |
red |
40 |
FDA 177.2600 aqueous & fatty foods, EC 1935, ADI free | -60/+200 |
| Silicone 714762 (79kB) More datasheets» |
VMQ |
white |
60 |
FDA 177.2600 aqueous & fatty foods, EC 1935, ADI free | -60/+200 |
| Silicone 714767 (83kB) More datasheets» |
VMQ |
transl. |
60 |
FDA 177.2600 aqueous & fatty foods, USP Class VI, EC 1935, ADI free | -60/+200 |
| Silicone 714768 (79kB) More datasheets» |
VMQ |
red |
60 |
FDA 177.2600 aqueous & fatty foods, EC 1935, ADI free | -60/+200 |
| Silicone 714217 (108kB) More datasheets» |
VMQ |
white |
60 |
FDA 177.2600 aqueous & fatty foods, USP Class VI, 3A, BfR, EC 1935, ADI free | -60/+200 |
| Silicone 714001 (104kB) More datasheets» |
VMQ |
transp. |
70 |
FDA 177.2600 aqueous & fatty foods, USP Class VI, BfR, EC 1935, ADI free | -60/+200 |
| Silicone 714330(*) (83kB) More datasheets» |
VMQ |
blue |
69 |
FDA 177.2600 aqueous & fatty foods, 3A, EC 1935, ADI free | -60/+220 |
| Silicone 714002 (131kB) More datasheets» |
VMQ |
Transp. |
75 |
FDA 177.2600 aqueous & fatty foods, USP Class VI, BfR, EC 1935, ADI free | -60/+200 |
| Silicone 714206 (80kB) More datasheets» |
VMQ |
red |
75 |
FDA 177.2600 aqueous & fatty foods, EC 1935, ADI free | -60/+220 |
| Silicone 714006 (85kB) More datasheets» |
VMQ |
red |
75 |
FDA 177.2600 aqueous & fatty foods, 3A, EC 1935, ADI free | -60/+220 |
| Silicone 714782 (79kB) More datasheets» |
VMQ |
white |
80 |
FDA 177.2600 aqueous & fatty foods, EC 1935, ADI free | -60/+200 |
| Silicone 714787 (79kB) More datasheets» |
VMQ |
transl. |
80 |
FDA 177.2600 aqueous & fatty foods, EC 1935, ADI free | -60/+200 |
| Silicone 714788 (79kB) More datasheets» |
VMQ |
red |
80 |
FDA 177.2600 aqueous & fatty foods, EC 1935, ADI free | -60/+200 |
| Teflex® Silicone (85kB) More datasheets» |
VMQ/FEP/PFA |
red |
70 |
FDA 177.2600 aqueous & fatty foods, USP Class VI, FDA 177.1550, EC 1935, ADI free | -60/+200 |
| Kalrez® 6221 (126kB) More datasheets» |
FFKM |
white |
70 |
FDA 177.2600 aqueous & fatty foods, USP Class VI, ADI free, | 260 |
| Kalrez® 6230 (126kB) More datasheets» |
FFKM |
black |
75 |
FDA 177.2600 aqueous & fatty foods, USP Class VI, ADI free | 260 |
